Antenna (5G Sub-6G) PCB

  • The design of the antenna: Active antenna

  • Line width / Line space: 40/40 μm

  • Board thickness: 0.8 – 1.4 mm

  • ~via (Laser Via/Pad): 50/140 μm – 75/170 μm

  • ~via alignment: ≤25 μm

  • Stack-up: 12-14 layers; HDI: 5+2+5, 6+2+6

  • Surface finishing: ENIG+I-Ag; ENIIG+OSP

  • Antenna patch tolerance: 15 μm

PCB

Orient Display is one of the world’s top-quality PCB manufacturers supporting double-sided PCB, multi-layer PCB,  HDI, and special PCB such as heavy copper PCB, MMW Automotive Radar PCB, etc. Quality certified ISO 9001, IATF 16949, ISO 13485, ISO 14001, and RoHS Compliant (Halogen free/Lead free).

Product Highlights
